DESCRIPTION

Basic Info.

Model NO.	2P1-10
Pressure	Medium
Valve Structure	Pilot Piston Structure
Power Supply	DC Solenoid Valve
Usage	Safety, Emptying, Drain, Flow Control
Standard	DIN
Application	Industrial Usage, Household Usage
Insulation	H Class
Protection	IP65
Transport Package	Carton
Specification	CE, ROHS, SGS, ISO9001
Trademark	VPC
Origin	Ningbo, China
HS Code	848180
Production Capacity	5000000000000PCS/Year

Product Description

Oxygen Machine On-off magnetic Valve 2P1-10 Normally Close 2/2 Way 12V Plastic Mini Air Solenoid Valves

Features:

1. The normal use of 25 million times above life. 2. low power consumption, quick response. 3. Quiet work,Can work long time no damage. 4. Plastic valve body, smaller size and lighter weight.

Model	2P1-10
Working Medium	Clean air
Control Style	Normal Close
Acting Type	Direct Acting
Tube Size	10mm
Diameter	0.8mm
Working Pressure	0~0.3MPa
Max Pressure	0.35MPa
Working Temperature	-5~80ºC
Voltage Range	±10%
Valve Body	Plastic
Excitation Time	<0.05s
Seal Material	NBR
Expected	25 million times

Ordering Code 2P Series Solenoid Valve

2P1 - 10 - AC220V

2P1→Type Code

2P1:2Port,2Position

10→Tube Size

10:10mm tube

AC220V→Standard VoltageDC1 DC24V AC24V 50/60HZ AC110V 50/60HZ AC220V 50/60HZ AC380V 50/60HZ
