Butterfly Valve with Flange/Wafer Pneumatic Actuator Output Torque

Products

Butterfly Valve with Flange/Wafer Pneumatic Actuator Output Torque

Butterfly Valve with Flange/Wafer Pneumatic Actuator Output Torque

AT series Pneumatic actuator for valves I ,Use The pneumatic actuator of AT series valve is driven through compressed ai

Send your inquiry

DESCRIPTION

Basic Info.
Acting Type Double Acting
Material Aluminum
Customized Customized
Structure Rack and Pinion
Applicable Air Source 0.4-0.7MPa
Output Torque 0-11000nm
Operating Storke 0-90°±5°
Transport Package Export Standard Box
Specification AT52-AT400
Trademark Bohai
Origin China
HS Code 8412390000
Production Capacity 5000PCS/Month
Product Description

Butterfly Valve with Flange/Wafer Pneumatic Actuator Output Torque


Butterfly Valve with Flange/Wafer Pneumatic Actuator Output Torque


Butterfly Valve with Flange/Wafer Pneumatic Actuator Output Torque


AT series Pneumatic actuator for valves
I ,Use
The pneumatic actuator of AT series valve is driven through compressed air, it is the driven device of open-close ball valve, butterfly valve and also other angle rotary valves. It is the perfect set to realized the remote centralization or separately control industrial automation pipeline.
According to the customer's demands, we can install solenoid valve , locator(the opening indication), signal feedback device, strainer, pressure reducing valve, all kinds of limited switch and manual device in the pneumatic actuator .
II, Main Technical Parameters
1. Medium: clean, dry and without corrosive compressed air
2. Working air pressure: 0.4~0.7 MPa
3. Working environmental pressure:
Standard type: -20ºC~+80ºC
High temperature type: -20ºC~+180ºC(short time can up to 200ºC)
4. Rotation Angle: 90 °+-3 °
5. Solenoid valve voltage: AC220V or DC24V (also according to the customer's requirement )
6. Output torque: Form 1 for AT double-acting actuator

III, Apperance and dimension connection

Butterfly Valve with Flange/Wafer Pneumatic Actuator Output Torque


Butterfly Valve with Flange/Wafer Pneumatic Actuator Output Torque


IV, Products characteristic
1. Gear rack and double piston symmetric structure design, action is quick and smooth, high precision, high output power, Through simple change of the piston assembly position available in the opposite direction and rotation.
  1. Extrusion of high quality aluminum alloy cylinder block, the precision machining of inner hole and outside surface of hard anodized(special condition anodic oxidation+Teflon coverage), the service life long, Low friction coefficient.
  2. One-piece design, all of the double action and single action actuator model have the same cylinder body and and cover, it is convenient to change the action type through add spring or take out of spring.
  3. Combined prediction operator safety spring set, whatever the install process or in using process, it can be convenient and safe to install or add spring quantity.
  4. The two separate adjusting screw of External side for installed on the valve actuator is more accurate and convenient, Regulating valve open and valve closed position, If you need to adjust the whole process, needing to add long adjusting screw at the two end cover configuration.
  5. Multiple acting indicator, the scene visual indicator, according with VID/VIE3845, Standard tank, can install and output all of the accessory, for example limited switch box, electro pneumatic positioner, position sensor(PEPPERL FUCHS, TURK)
  6. Air supply connector accord with standard, Solenoid valve of standards can be installed directly.
  7. Rack on the back of the composite bearing and the piston guide ring and the output shaft bearing, etc to prevent metal to metal friction, and increase the lubrication, low friction, long life.
  8. All fasteners are stainless steel materials, corrosion for a long time.
  9. Connection part conform to the new international standard specifications ISO05211,DIN337(F03-F25) making production installation interchangeable , general.

Butterfly Valve with Flange/Wafer Pneumatic Actuator Output Torque


Q: Are you trading company or manufacturer ?
A: We are factory Located In Tianjin, China.
Q: What's your product range?
A: We produce Butterfly valve, Gate valve, Check valve, Y strainer ,Water Controlling Valve and other Pipe Accessories .
Q: What's Execution Standard?
A: ISO/ANSI/DIN/JIS/ EN/GOST/S standard.
Q: What's your Strong product ?
A: Centre Line Butterfly valve, Eccentric Butterfly valve ,Resilient Seat Gate valve, and largest size to DN3200 .
Q: How long is your delivery time?
A: Generally it is 10 days if the goods are in stock. or it is 35 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=10000USD, 100% in advance. Payment>=10000USD, 30% T/T in advance ,balance before shipment.
